Description
The PetroClear model 40930W is a particulate removing and water sensing spin-on filter designed to remove particulate and to sense both free and emulsified water from neat gasoline, diesel, Biodiesel, ULSD (Ultra Low Sulfur Diesel), kerosene and fuel oils.
The 40930W utilizes a standard 1"–12 UNF mounting thread ref. (3/4" flow) required for most spin-on filter adapters used in Gilbarco, Wayne, Bennet, Tokheim and other major manufacturers’ dispensers, as well as with adapters used in the aftermarket.
Adapters are available for models 40910W and 40930W in aluminum and cast iron. These single adapters are available in both 3/4" and 1" NPT or BSP inlet/outlet threads.
The PetroClear 40930W Cross References with the Cim-Tek 70067, 260HS-30.
| Model | 40930W |
|---|---|
| Filter Type | Spin-On |
| Media Type | *Cellulose |
| Micron Rating | 30 Micron (nominal) |
| Diameter | 3.70" |
| Height | 8.60" |
| Mounting Thread | 1" – 12 UNF |
| Flow | 3/4" flow |
| Shell Thickness | 0.020 |
| Gasket Material | Buna N |
| Collapse (Min.) | 150 psid (10.3 bar) |
| Burst (Min.) | 250 psi (17.2 bar) |
| Max. Operating Temp. | 250°F (139°C) |
