Description
Normally closed solenoid valves are used to help prevent the accidental siphoning of product from a tank in the event of a fracture in the pipe or other cause for leak downstream and below the liquid level. Generally installed on the dispensing side of a fuel system pipeline. The valve opens upon the receipt of an electronic signal such as when a dispenser or pump is switched to the on position.
Ordering Details
- 710SS has a stainless steel body
- 710SS20751V 3/4" Solenoid Valve
- 710SS21001V 1" Solenoid Valve
- 710SS21501V 1 1/2" Solenoid Valve
- 710SS22001V 2" Solenoid Valve
- 710SS22001V 3" Solenoid Valve
Construction Details
- Body: Stainless Steel
- Seals: Viton, Teflon
- Power: 120/60 Volt AC Coil
- Solenoid housed in an integral, watertight, explosion-proof shell
NOTE: Product can only be pumped in one direction, the direction of the flow arrow. Not designed for use as an overfill prevention or process control valve.
