Description
The PetroClear model 51130W is a particulate removing and water sensing spin-on filter designed to remove particulate and to sense both free and emulsified water from neat gasoline, diesel, Biodiesel, ULSD (Ultra Low Sulfur Diesel), kerosene and fuel oils.
The 51130W utilizes a standard 1.5"-16 UNF mounting thread ref. (1" flow) required for most spin-on filter adapters used in aftermarket and/or high-flow applications.
Adapters are available for models 51110W and 51130W in aluminum. These adapters are available in both NPT and BSP inlet/ outlet threads. Inlet/outlet sizes are available in 1" and 1-1/2" single adapters. Adapters are also available in a dual style with both 1.5" and 2" inlet/outlet (2"– 4" bolt SAE flange combination).
The PetroClear 51130W Cross References with the Clim-Tek 70068, 800HS-30.
| Model | 51130W |
|---|---|
| Filter Type | Spin-On |
| Media Type | Cellulose with super absorbent media |
| Micron Rating | 60 Micron (nominal) |
| Diameter | 5.00" |
| Height | 11.37" |
| Mounting Thread | 1.5" – 16 UNF |
| Flow Rate | 40 gpm (151 lpm) |
| Flow | 1" flow |
| Shell Thickness | 0.020 |
| Gasket Material | Buna N |
| Collapse (Min.) | 150 psid (10.3 bar) |
| Burst (Min.) | 200 psi (13.5 bar) |
| Max. Operating Temp. | 250°F (139°C) |
