40530A-AD Petro-Clear Filter

Weight:

SKU:

Categories: All Products, FIlters

Product type: Filters

Brands: Petro-Clear

Tags: Filters

Availability:

Description

The PetroClear model 40530A-AD is a spin-on filter designed to remove particulate, detect and stop flow of phase separation (Ethanol water) in Ethanol blended fuels. UL recognized

The 40530A-AD is designed to remove particulate and to detect and react to phase separation in Ethanol blended gasoline and slow flow as an indicator to the presence of phase separation.

The chemical center core assembly detects and reacts to phase separation and significantly restricts flow through filters.

PetroClear models 40510A-AD and 40530A-AD utilize a standard 1.5"-16 UNF mounting thread ref. (1" flow) required for most spin-on filter adapters used in aftermarket. Adapters are available for models 40510A-AD and 40530A-AD in aluminum. These single adapters are available in both 3/4" and 1" NPT or BSP inlet/outlet threads.

IT WILL NOT SENSE NOR REACT TO WATER IN NON-ALCOHOL BLENDED GASOLINE (NEAT GASOLINE)

Model 40530A-AD
Filter Type Spin-On
Media Type Cellulose
Micron Rating 30 Micron (nominal)
Diameter 3.70"
Height 5.36"
Mounting Thread 1.5" – 16 UNF
Flow Rate 25 gpm (94.6 lpm)
Flow 1" flow
Shell Thickness 0.02
Gasket Material Buna N
Collapse (Min.) 150 psid (10.3 bar)
Burst (Min.) 500 psi (34.5 bar)
Max. Operating Temp. 250°F (139°C)
Min. Operating Temp. -20°F (-28.9°C)

PETROCLEAR FILTERS ARE NOT TO BE USED IN AVIATION FUEL APPLICATIONS.
